LONGER RAY5 10W Multi-Functional Laser Module Set, Double Beam Technology, 50mm Focal, 20000H Working Life, 0.06mm² Ultra-fine Laser Spot

Highlights

Double Beam Technology & Powerful Cutting
Adopting compressed double beam technology, it is more powerful and has finer laser beams and 50mm long laser focal. The max engraving speed is 10000mm/min, and the maximum cutting thickness can be up 30mm, 8 -10mm thickness of plywood can be cut by one pass.
Precision Engraving
0.06 square millimeter ultra-fine laser spot is 2 times thinner than ordinary lasers, making RAY5’s cutting and engraving more precise and with fewer burn marks.
Eye Protection
Equipped with the latest panoramic filter glass protective cover, which plays a good role in protecting the eyes, filtering 97% of ultraviolet rays, no need to wear additional protective glasses. And the service life of the laser is about 20,000 hours.
1000+ Applicable Material
Support engraving materials: All wood, paper, plastic, leather, PCB board, aluminum oxide, non-reflective plating, lacquered metal, etc.
Support cutting materials: Cardboard, non-woven fabric, light wood, Acrylic material, thin plastic board, etc.
Wide Application Scene
It is suitable for making company logos, signage, Christmas ornaments, spice jars, QR codes and barcodes for clients, photo engraving, personalized products, business cards, wine glasses, key chains, customized jewelry, theme toy boxes, coasters, artwork, celebration and so on.



Specification

General	Brand: LONGER Type: Laser Module Set Model: RAY5 10W
Specification	Model: LC40F50 (RAY5 10W) Laser Technology: Compressed Double Beam Technology Wavelength: 450 – 460 nm Max Power Input: 12V 3.2A Optical Power Output: 10 – 11W Focus Type Fixed Focus: 50mm Focal length Ultra-fine Laser Spot: 0.06×0.06mm2 Laser Class: FDA Class IV, or Class 4 IEC standard Applicable Material: Engraving: Plywood, Basswood, Hardwood, Pinewood, Acrylic, Kraft paper, Stainless steel, Aluminum alloy, Ceramics, etc. Cutting: 10mm Basswood, 14mm Pinewood, 6mm Acrylic, 4mm Bamboo, Kraft paper, etc. Working Life: 20000 hours Working Temperature: 0 – 70 Celsius
Weight & Size	Product Weight: 285g Package Weight: 435g Package Size(L x W x H): 23x10x12.5cm
Package Contents	1 x 10W Laser Module 1 x Focusing Column
